Model | ZL38-08 | ||||||||
Working Voltage Range | DC: 6-24V | ||||||||
Rating Power | 6V: 0-17W / 12V: 0-17W / 24V: 0-25W | ||||||||
Static Water Head | 0-6 M | ||||||||
Static Flow Rate | 0-12 L/min | ||||||||
Lifespan | Continuous operation≤24hrs, under normal working surrounding >20000Hr | ||||||||
Working Environment | Liquid: From weak acid to weak base, workable on land (Non submersible) | ||||||||
Max Noise | Under normal working status, 1M distance over test instrument <40dB | ||||||||
Max Working Temperature | Under normal surroundings, fluid medium temperature≤70℃ | ||||||||
Application | Solar water circulation system, Hot shower, Engine cooling water circulation, Small fountain, Aquarium, etc. | ||||||||
Size | IP Grade | Inlet | Outlet | Remark | |||||
Length（mm） | width（mm） | Height（mm） | OD（inch） | ID（mm） | OD（inch） | ID（mm） | Inlet and outlet with forward spinning standard pipe thread | ||
96 | 47 | 90 | IP67 | G1/2〞standard pipe thread | φ13 | G1/2〞standard pipe thread | φ13 | ||
Remark: It’s for reference only, the one based on the customer’s endorsement demands shall prevail!
