Model | ZL32-05 | |||||||||
Working Voltage Range | DC: 6V-24V | |||||||||
Rating Power | 6V: 0-4.9W / 12V: 0-6.5W / 24V: 0-6.5W | |||||||||
Static Water Head | 0-3.0 M | |||||||||
Static Flow Rate | 0-3.5 L/min | |||||||||
Lifespan | Continuous operation≤24hrs, under normal working surrounding >20000Hr | |||||||||
Working Environment | Liquid: From weak acid to weak base, work in water (Submerged) | |||||||||
Max Noise | Under normal working status, 1M distance over test instrument <35dB | |||||||||
Max Working Temperature | Under normal surroundings, fluid medium temperature ≤70℃ | |||||||||
Application | Solar water circulation system, flower and plant watering, footbath, etc. | |||||||||
Size | Protectio Category | Inlet | Outlet | Remarks | ||||||
Length（mm） | Width（mm） | Height（mm） | OD（mm） | ID（mm） | OD（mm） | ID（mm） | Inlet and Outlet with non-slip insert | |||
45 | 34 | 66 | IP68 | φ9.4 | φ6.6 | φ10 | φ5 | |||
Remark: It’s for reference only, the one based on the customer’s endorsement demands shall prevail!
